3 Tonne Excavator – Kubota Kx030 Canopy Top

Get work done where others can’t, with the Kubota KX030-4 compact excavator. It’s designed to fit into small or tight spaces, while simultaneously boasting the largest cab in its class. Don’t let any job constrain you: get it done with efficiency and comfort.

Day: Weekend:  Week: Month:
350$ CALL 1400$ 4200$

Request Reservation
First/Last

Compact 4’11” width

The KX030-4 is powerful but compact: its 4’11” (1500 mm) width enables it to fit into tight spaces. It can handle tough jobs, too, with its bucket digging force of 6924 lbs. within a design that’s well-balanced and efficient

Easily and safely towable

Get it to the job site without extra effort. The Cab model weighs under 7000 lbs. so it can be towed with a standard license, depending on weight of trailer. And to get it there safely, tie-down points are found on the track frame, swivel frame, and dozer.

Largest Cab in its class

Operator comfort is a priority. That’s why the Kubota KX030-4 features the largest cab in the class, along with a large door entrance to suit any size of operator. Inside, there’s plenty of floor space and leg room.

Specs

Model
Model name – KX030-4
Engine
Model – V1505-E4-BH-3USA
Rated engine speed – 2250 rpm / 2250 rpm
Output (SAE J1995 gross) – 24.7 HP / 18.4 kW
Output (SAE J1349 net) – 23.7 HP / 17.7 kW
Hydraulic system
Auxiliary hydraulic flow
Pump capacity – 8.3 gpm / 31.5 l/min
Breakout force
Bucket – 6824 lbf / 3140.7 kgf
Arm – 3484 lbf / 1580.6 kgf
Dimensions and weight
Ground clearance – 11.6 in / 295 mm
Overall height – 95 in / 2420 mm
Overall length – 181.1 in / 4600 mm
Overall width – 59 in / 1500 mm
Blade
Width – 59 in / 1500 mm
Height – 11.8 in / 300 mm
Maximum lift above ground – 13.8 in / 352 mm
Maximum drop below ground – 13.5 in / 345 mm
Operating weight
Including operator’s weight @ 175 lbs. – 6272 lb / 6426 kg
Tracks
Type – Rubber / Steel
Drive system
Travel speed
Low – 1.7 mph / 2.7 km/h
High – 2.7 mph / 4.3 km/h
Maximum traction force – 7330 lbf / 3325 kgf
Crawler length – 77.9 in / 1980 mm
Shoe width – 11.8 in / 300 mm
Ground contact pressure – 3.9 psi / 0.27 kg/cm2
Tumbler distance – 61.4 in / 1560 mm
Swing system
Unit swing speed – 9.2 rpm / 9.2 rpm
Boom swing angle
Left – 76 deg / 76 deg
Right – 57 deg / 57 deg
Fluid capacities
Hydraulic Oil
Reservoir – 9 gal / 33.9 l
System – 13.7 gal / 52 l
Fuel
Reservoir – 12.7 gal / 48 l
ROPS / FOPS
Type – Canopy / Cab
